HPE
Hewlett Packard Enterprise (Q1F45A) ATEN CS1308 G2 0x1x8 Analog KVM Switch
- SKU:
- Q1F45A
- MPN:
- Q1F45A
- Availability:
- On backorder. Usual lead time is 3 weeks. Contact Us for Availability
- Shipping:
- Calculated at Checkout
Description
Description | |
Manufacturer: | Hewlett Packard Enterprise |
Manufacturer Website Address: | https://www.hpe.com/au/ |
Brand Name: | HPE |
Product Model: | CS1308 |
Product Name: | ATEN CS1308 G2 0x1x8 Analog KVM Switch for HPE Servers |
Marketing Information: | Do you need consolidated server access, management, and control for desktop and rack-mount environments? ATEN G2 KVM Switches are Suitable for Installation in Most IT Environments ATEN G2 KVM Switches for HPE are qualified for integration into HPE racks using HPE Factory Integration Services. Mounting Hardware is included for easy installation into HPE G2 Advanced and Enterprise Racks. Attachable foot pads are included for deployment of the switch in a desktop configuration. ATEN G2 KVM Switches for HPE Support Three Different Methods to Select Your Target Device ATEN G2 KVM Switches for HPE feature front side push-button selection with LED indicators allow for direct selection of the target device. Keyboard hot-key support allows target device selection when the switch is inaccessible inside the rack. A menu-driven multi-lingual OSD (On Screen Display) feature allows for target device selection through a graphical interface on the connected monitor or KVM console. ATEN G2 KVM Switches for HPE Allow Access to up to 256 Servers Through a Single KVM Installation ATEN G2 KVM Switches for HPE come in 4, 8, and 16 port models to support up to 16, 64, and 256 devices respectively through two level tiering/cascade technology. Switch connectivity to individual servers is supported through interface adapter cable options that support servers using USB with both VGA and Display Port video connections. ATEN G2 KVM Switches for HPE Provide Security Features to Prevent Unauthorized Users ATEN G2 KVM Switches for HPE feature two level password security so only authorized users view and control connected devices. ATEN G2 KVM Switches for HPE support up to four separate user profiles and an administrator profile. |
Packaged Quantity: | 1 |
Product Type: | KVM Switchbox |
Technical Information | |
Number of Computers Supported: | 4 |
Number of Local Users Supported: | 1 |
Video | |
Maximum Video Resolution: | 2048 x 1536 |
Interfaces/Ports | |
USB: | Yes |
VGA: | Yes |
Number of USB Ports: | 3 |
Number of VGA Ports: | 8 |
Power Description | |
Input Voltage: |
|
Input Voltage Range: | 100V AC to 240V AC |
Physical Characteristics | |
Form Factor: | Rack-mountable |
Rack Height: | 1U |
Height: | 44 mm |
Width: | 437.2 mm |
Depth: | 161.3 mm |
Weight (Approximate): | 1.89 kg |
Miscellaneous | |
Environmentally Friendly: | Yes |
